Terex Manlift Specifications
Based in Westport, Connecticut, Terex specializes in making construction equipment. They produce machines like boom lifts, aerial lifts and manlifts. These types of equipments are designed to facilitate access to areas which are hard to reach, roofs and buildings, large equipment, amongst other things. A manlift, as defined by the U.S. Occupational Safety and Health Administration or also known as OSHA refers to a power-driven endless belt. This belt only moves in one direction and includes steps or handholds or paltforms that are attached to the unit in order to transport workers from each floor.
TB85
The Terex TB85 offers a maximum working height of 91 feet. Moreover, the maximum height of the platform reaches 85 feet. The maximum width of this model is 8 feet, 1 and 1/2 inches. The TB85 has dimensions measuring 9 feet, 1-inch high and 9 inches wide by 36 feet. This model offers a reach of 70 feet. The TB85 has a boom angle above horizontal reaching 75 degrees and below horizontal measures at -14 degrees.
Terex TB100
The Terex TB100's maximum working height is 106 feet and the maximum height of the platform is 100 feet. When the TB100 is stowed it is 8 feet, 1 1/2 inches wide by 9 feet high by 8 feet. The unit's maximum width is 8 feet, 1 1/2 inches. The boom angle above horizontal is 75 degrees and below horizontal is 14 degrees. The horizontal reach measures at 67 feet, 4 inches.
TB110
The Terex TB110 man lift reaches a max height of 100 feet, while the max working height reaches 116 feet. The model is 9 feet, 4 inches high x 8 feet wide when stowed away. The TB110 offers a horizontal reach of 67 feet and a maximum width of 8 feet. This model has a boom angle of 75 degrees above horizontal plus 10 degrees articulating. It measures -105 degrees articulating and below horizontal it is -14 degrees.
